Features:

• Conductor: Solid bare copper, 24 AWG
• Pairs: 4 twisted pairs (x4PR), color-coded for easy identification
• Insulation: High-density polyethylene (HDPE)
• Jacket: PVC or LSZH (Low Smoke Zero Halogen), depending on model
• Outer Diameter: Typically around 4.8–5.0 mm
• Rip Cord: Included for easy jacket removal
• Impedance: 100 ± 15 Ω
• DC Resistance: ≤28.6 Ω/km
• Capacitance Unbalance: ≤330 pF/100m
• Insulation Resistance: ≥5000 MΩ/km
• Propagation Delay: ≤45 ns/100m
• Temperature Range: -20°C to +75°C
• Minimum Bend Radius: 8 × cable O.D.
• Tensile Strength: ≥13.5 MPa (sheath)
• Elongation: ≥150% (sheath), ≥300% (insulation)
• Cold Bend Test: No visible cracks at -20°C
• 10/100/1000 Mbps Ethernet (Gigabit Ethernet)
• ATM 155/622 Mbps
• Composite video transmission
• Horizontal cabling in structured networks
