Features :

• Type: Panel Mount Male Connector Assembly
• Series: MX150
• Part Number: 1480286001
• Circuits: 6 positions, dual row
• Keying Option: A
• Color: Black
• Material: Nylon housing with silicone gasket
• Mounting Style: Panel mount
• Pitch: 3.5 mm
• Operating Temperature: -40°C to +125°C

Wire  :

• Wire Type: Hook-up wire
• Conductor: Tinned copper, stranded (17 strands of 0.16 mm)
• Gauge: 22 AWG
• Insulation: Cross-linked polyethylene (XLPE)
• Rated Temperature: 105°C
• Rated Voltage: 300V
• Outer Diameter: ~1.30 mm
• Insulation Thickness: ~0.23 mm
• Resistance: ~59.4 Ω/km
• Flame Test: Passes UL VW-1 and FT1/FT2 vertical flame tests
• Compliance: UL758, RoHS, REACH
