Features :

• Connector Type: Board-in crimp-style connector
• Series: SAN
• Number of Positions: 12 circuits (single row)
• Pitch: 2.0 mm — compact spacing for high-density PCB mounting
• Mounting Height: Approx. 6.0 mm
• Thickness: Approx. 3.25 mm
• Termination Style: Crimp-style contacts (e.g., SAN-002T-0.8A or SAN-002T-0.8K)
• Mounting Style: Direct board-in (no header required)
• Housing Features: Housing lances for secure retention
• Rated Current: 2A AC/DC (AWG #24)
• Rated Voltage: 250V AC/DC
• Operating Temperature Range: -25°C to +85°C
• Insulation Resistance: ≥ 1000 MΩ
• Withstanding Voltage: 800V AC/min
• Applicable Wire Sizes: AWG #30 to #24
• Applicable PCB Thickness:
• Type A contact: 1.2 mm or 1.6 mm
• Type B contact: 1.6 mm
• Compliance: RoHS compliant
• Color: Typically orange for easy identification

Wire :

• Type: Hook-up wire for Class 2 circuits
• Conductor: 7 strands of 0.16 mm tinned copper (#26 AWG)
• Insulation: Thin-wall PVC (Polyvinyl Chloride)
• Outer Diameter: Approx. 0.68 mm
• Voltage Rating: 30V
• Temperature Rating: 80°C
• Flame Resistance: Passes UL VW-1 flame test
• Use Case: Internal wiring in electronic devices and equipment
• Compliance: UL758, UL1581, RoHS compliant
• Color Options: Black and white are standard; other colors available on request
