Cord End Terminal / Bootlace Ferrule
Features :
- Wire Size: 12 AWG (≈ 4 mm²)
- Ferrule Length: 12 mm
- Total Length: ~19.4–20 mm (varies slightly by brand)
- Material: Tin-plated copper for conductivity and corrosion resistance
- Insulation: Nylon or plastic sleeve (color-coded, e.g., orange or grey)
- Color Coding: Helps identify wire size and simplifies installation
- Mounting Style: Crimp (requires ferrule crimping tool)
- Rated Current: ~35 A
- Rated Voltage: Up to 600 V
- Temperature Range: -40°C to +105°C
- Flammability Rating: UL94V-0 (for insulated versions)
