Plug Housing For Female Socket Contacts DT06-08SA

Features :

  • Connector Type: Plug housing for female socket contacts
  • Number of Positions: 8
  • Pitch: 4.44 mm (centerline spacing)
  • Mounting Style: Free-hanging (in-line cable mount)
  • Termination Style: Crimp
  • Fastening Type: Latch lock for secure mating
  • Color: Gray
  • Sealable: Yes — includes integrated environmental sealing
  • Housing Material: Glass-filled polyamide (PA)
  • Operating Temperature: -55°C to +125°C
  • Protection Rating: IP68 & IP6K9K — dust-tight and high-pressure water resistant
  • Flammability Rating: UL94 V-0
  • Rated Voltage: Up to 250 V AC/DC
  • Current Rating: Up to 13 A (with Size 16 contacts)
  • Mating Pin Diameter: 1.59 mm
  • Length: ~30.91 mm
  • Width: ~19.71 mm
  • Height: ~37.21 mm
  • Compatible Wire Insulation Diameter: 2.23–3.68 mm
  • Automotive wiring harnesses
  • Off-road and heavy-duty vehicles
  • Marine and industrial equipment
  • Power and signal transmission in harsh environments
