Features :

• Connector Type: Wire-to-board receptacle housing
• Series: SH
• Number of Positions: 8 circuits (single row)
• Pitch: 1.00 mm — ultra-compact for high-density applications
• Termination Style: Crimp-style contacts (e.g., SSH-003T-P0.2-H)
• Mounting Style: Free-hanging (in-line), cable mount
• Contact Type: Female socket (contacts sold separately)
• Housing Material: Polybutylene Terephthalate (PBT), UL94V-0 flame-retardant
• Operating Temperature Range: -25°C to +85°C
• Voltage Rating: 50V AC/DC
• Current Rating: 1A
• Contact Resistance: ≤ 20 mΩ
• Insulation Resistance: ≥ 100 MΩ
• Color: Natural (off-white)
• Compliance: RoHS3 compliant, REACH unaffected
• Packaging: Bulk
• Applications: Compact consumer electronics, sensors, and signal transmission

Wire :

• Type: Flat ribbon cable
• Conductor: 7 strands of 0.10 mm tinned copper (#30 AWG)
• Insulation: PVC (Polyvinyl Chloride), grey with red stripe
• Pitch: 1.00 mm between conductors
• Voltage Rating: 300V
• Temperature Rating: 105°C
• Flame Resistance: UL VW-1 and CSA FT1 compliant
• Use Case: Internal wiring for computers, appliances, and data connections
• Compliance: UL2651 standard, RoHS compliant
• Packaging Options: Reel wrapping, bobbin rolling, or cardboard protection
