Features:

• Pitch: 1.50 mm
• Circuits: 7 positions
• Termination: Crimp-style contacts
• Locking Mechanism: Friction lock
• Rated Current: 3A AC/DC
• Rated Voltage: 350V AC/DC
• Operating Temperature: -25°C to +85°C
• Contact Resistance: ≤ 20 mΩ
• Insulation Resistance: ≥ 1000 MΩ
• Withstanding Voltage: 500V AC/min
• Applicable Wire Range: AWG #24–28
• Mounting Style: Free-hanging; mates with SMT headers
• Compliance: RoHS compliant

Wire:

The UL10368 #24 wire is a single-core hook-up wire used for internal wiring in electrical and electronic devices. It has a stranded tinned copper conductor for flexibility and corrosion resistance, and is insulated with cross-linked polyethylene (XLPE) for better heat, chemical, and abrasion resistance. This wire is rated for 300V and 105°C, making it suitable for demanding environments like control panels, appliances, and industrial equipment
