Features :

• Connector Type: Wire-to-board receptacle housing
• Number of Positions: 18 circuits (dual-row configuration)
• Pitch: 2.00 mm — compact spacing for high-density signal connections
• Row Spacing: 2.00 mm between rows
• Termination Style: Crimp-style contacts
• Mounting Style: Free-hanging (in-line), cable mount
• Contact Type: Female socket (contacts sold separately)
• Housing Material: Polyamide (PA), flame-retardant and durable
• Operating Temperature Range: -30°C to +85°C
• Color: Black
• Compliance: RoHS3 compliant, REACH unaffected
• Flame Test: UL horizontal flame test compliant
• Applicable Wire Sizes: AWG #22 to #30

Series Features:

• Space-saving dual-row design within 5 mm width
• Broad variation including crimp and insulation displacement types
• Compatible with automatic insulation displacement machines for efficient harnessing

Wire :

• The 6711 WH001 is a 26 AWG stranded hook-up wire designed for internal wiring in electronic and electrical equipment. It features 7 strands of tinned copper for flexibility and corrosion resistance, and is insulated with modified polyphenylene ether (mPPE) — a halogen-free material offering excellent mechanical, thermal, and chemical performance. Rated for 600V and -40°C to +105°C, this wire meets UL Style 11028 and is RoHS3 compliant, making it ideal for eco-conscious designs.
