Features :

• Resistance @ 25°C: 10 kΩ
• Tolerance: ±2%
• B-Value (B25/85): 3977 K — defines how resistance changes with temperature
• Power Rating: 500 mW
• Operating Temperature: -40°C to +125°C
• Mounting Style: Through-hole (radial leads)
• Package: Bead-type with epoxy coating and blue dot marking
• Lead Spacing: 2.54 mm

Wire :

• Cable Type: Halogen-free data cable
• Core Configuration: 2 × 0.5 mm² (AWG 20)
• Conductor Material: Bare copper, finely stranded (Class 5)
• Core Insulation: Polyethylene (PE) for low capacitance
• Outer Sheath: Thermoplastic compound, grey (RAL 7005)
• Sheath Properties: Flame-retardant, halogen-free, cadmium-free, silicone-free
• Outer Diameter: ~4.8 mm
• Weight: ~30 kg/km
• Rated Voltage: 500 V
• Test Voltage: 1200 V (core/core)
• Operating Temperature:
• Fixed Installation: -40°C to +70°C
• Flexible Use: +5°C to +70°C
• Minimum Bending Radius:
• Fixed: 4× outer diameter
• Flexible: 7.5× outer diameter
• CPR Classification: Eca, Fca (fire safety)
