Features :

• Connector Type: Rectangular plug
• Series: MQ172
• Number of Positions: 3 circuits
• Pitch: 0.80 mm — ultra-low profile for space-saving designs
• Contact Type: Male pin
• Termination Style: Solder termination
• Mounting Style: Free-hanging (in-line), cable mount
• Contact Finish: Gold-plated for enhanced conductivity and corrosion resistance
• Housing Material: Polyamide (PA), black color
• Operating Temperature Range: -30°C to +75°C
• Voltage Rating: 40V AC / 30V DC
• Current Rating: 3A
• Insulation Resistance: ≥ 1 GΩ
• Wire Gauge Range: AWG #32 to #24
• Compliance: RoHS compliant
• Applications: Power-to-board connections in compact electronic devices

Wire :

• Type: Flexible multi-core cable
• Conductors: 3 cores, each made of stranded tinned copper (#28 AWG)
• Insulation: PVC or flame-retardant polyethylene (FRPE)
• Jacket: Durable TPU (Thermoplastic Polyurethane)
• Voltage Rating: 300V
• Temperature Rating: 80°C
• Flame Resistance: Passes UL VW-1, FT1, FT2 flame tests
• Shielding (Optional): Foil or braid with ≥65% coverage
• Shape: Round, oval, or flat depending on cable lay
• Use Case: Internal wiring in electronics, waterproof connectors, spiral cables
• Compliance: UL758, UL1581, RoHS, REACH, WEEE
