Connectors Powerlok 10mm G2 3pos Rcpt Flat  Busbar D10 Hole X Keying With HVL,  Amphenol : Pl083x-301-10m6-2

Features :

• Series: PowerLok G2
• Connector Type: Receptacle (RCPT), flat busbar termination
• Positions: 3 (3POS)
• Busbar Hole: D10 (10 mm diameter)
• Keying: X-keyed for mating alignment and safety
• High Voltage Interlock (HVIL): Integrated for enhanced safety in high-voltage systems
• Current Rating: Up to 300 A
• Voltage Rating: Up to 1000 VDC
• Mounting Style: Panel mount
• Mounting Angle: Straight
• IP Rating: IP67 (sealed against dust and water)
• Operating Temperature: -40°C to +125°C
• Shell Material: Aluminum alloy with gray zinc plating
• Shielding: 360° electromagnetic shielding
• Contact Technology: RADSOK® for low contact resistance and high reliability
• Vibration Resistance: Suitable for high-vibration environments like trucks and construction equipment
• EV power distribution units (PDUs)
• Battery packs
• Inverters and motors
• Agricultural and off-road vehicles
